飛機模型展覽是大多數人認識了解飛機的主要途徑之一，如果在展覽過程中飛機處于靜止?fàn)顟B(tài)，不生動，缺乏觀賞的趣味性，不符合人們對飛機的基本認知，其次，在展覽中對飛機存在單一性，不可隨意匹配任意型號飛機，實用性低。
The airplane model exhibition is one of the main ways for most people to know about airplanes. If the airplane is in a static state during the exhibition, it is not vivid, lacks interest in viewing, and does not conform to people's basic understanding of airplanes. Secondly, there is a oneness in the airplane in the exhibition, and you cannot match any type of airplane randomly, which is low in practicality.
為了現有技術的不足，本實用新型提供一種用于
大型飛機模型展的滑軌，其結構簡單，使展覽中靜止的飛機可以滑動，增添展覽的趣味性，并且可以任意匹配型號大小不一的飛機，增強實用性。
In order to solve the shortcomings of the prior art, the utility model provides a slide rail for a large aircraft model exhibition, which has a simple structure, enables the static aircraft in the exhibition to slide, increases the interest of the exhibition, and can arbitrarily match the aircraft of different models and sizes, enhancing the practicability.
本實用新型其技術問題所采用的技術方案是一種用于大型飛機模型展的滑軌,包括軌道、安裝板、牽引裝置，所述軌道包括相互平行的主軌道和兩條輔軌道；
The technical scheme adopted by the utility model to solve its technical problems is a slide rail for large aircraft model exhibition, which includes a track, a mounting plate and a traction device. The track includes a main track and two auxiliary tracks that are parallel to each other;
主軌道位于安裝板的處，以主軌道為對稱設置有少兩對橫向滑槽，滑槽側面距離安裝板邊界10㎝-20㎝；
The main track is located in the center of the mounting plate, and at least two pairs of transverse chutes are symmetrically arranged with the main track as the center. The side of the chute is 10 cm - 20 cm from the boundary of the mounting plate;
所述滑槽上設置有滑塊對，輔軌道設置在滑塊對上，所述主軌道和輔軌道均包括夾角軌道和中端軌道，中端軌道設置在安裝板上，其兩端與夾角軌道連接，夾角軌道向安裝面上方延伸，其與安裝板所處平面夾角為30°-40°，所述牽引裝置位于主軌道前方。
The slide block pair is arranged on the chute, and the auxiliary track is arranged on the slide block pair. The main track and the auxiliary track both include the angle track and the middle end track. The middle end track is arranged on the mounting plate, and its two ends are connected with the angle track. The angle track extends above the mounting surface, and the angle between the angle track and the plane where the mounting plate is located is 30 ° - 40 °. The traction device is located in front of the main track.
